Puertos
1*10/100 Mbps RJ45
Botones
Reset, WPS
LED
1 * Signal LED
1 * WPS LED
1 * Power LED
Fuente de alimentación
9V 0.8A, built-in
Tipo de enchufe
National Standard, US Standard, European Standard, UK Standard, Brazil
Standard
Consumo de potencia
No-load: 2.8W, Full-load: 5.2W
Dimensiones
80mm * 58mm * 48mm
Estándar y protocolo
IEEE 802.11a, IEEE 802.11n, and IEEE 802.11ac wave2 on 5 GHz
IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n on 2.4 GHz
Velocidad
802.11b: 11 Mbps
802.11g: 54 Mbps
802.11n: 300 Mbps
802.11ac: 867 Mbps
Banda de frecuencia
11n: 2.412-2.484 GHz
11ac: 5.15-5.25 GHz
Potencia de transmisión
2.4 GHz: 16dBm
5 GHz: 12dBm
RSSI
2.4 GHz
11b-1M:-97dBm
11g-54M:-76dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
5 GHz:
11a-6M:-95dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
11ac-80M-MCS9:-63dBm
Antena
2 * External 2dBi dual-band omni-directional antenna (non-detachable)
Canales
11n: 20/40MHz by default
11ac: 80MHz by default
Modo de funcionamiento
Repeater Mode
AP Mode
Seguridad inalámbrica
Default encryption mode: Mix WPA-PSK/WPA2-PSK
WPA algorithm: TKIP
Servidor DHCP
Supported
Herramientas del sistema
Firmware upgrade, Restore factory settings, Login password, and
Reboot Temperatura
Operating temperature:0ºC~40ºC
Storage temperature:-40ºC~70
Humedad
Operating humidity:(10 90)% RH, non-condensing
Storage temperature:5%~90%RH, non-condensing
Contenido del paquete
1 * AC1200 Dual Band WiFi Repeater
1 * Quick Installation Guide
